Specification

Here you will find a detailed breakdown of my Gardner Douglas MkIV project. This is where the rubber meets the road, so to speak, detailing the unique aspects that make this build truly mine.

This was the tricky one as it is so easy to get immersed, sidetracked, mesmerised and overwhelmed with "stuff." To counter this, I created a basic list of my required and desired elements; they being less than the sum of the whole, and they being the pieces of my puzzle that had a well-defined but ever-changing picture..

So here's my Car's Specifation

Model: Gardner Douglas GDEuro (Mk 4)

Battery:

Body Shell:

  • Gelcoat (Jet Black (RAL9005))
  • No stripes
  • No bumpers
  • Integrated air scoop
  • Aston type fuel filler
  • P700 headlights
  • Two roll-bars

Chassis: Euro Classic (Deep Dish Wheels)

Clutch:

Cockpit:

  • Dashboard & Fitments:
    • Dashboard: Flat-bottomed and based on the classic 427 S/C configuration
    • Dials: Speedhut
    • Switches: Old-fashioned Bakelite type (black)
    • Warning Lights: Chrome LED
    • Accessory Outlets: One 12v (cigarette type) and one 2-port USB socket
    • Footwell lights: LED
    • Steering Column Stalks: Standard Vauxhall black plastic type that came with the column. (I didn't replace them in favour of the GD polished steel option)
  • Trim:
    • Black carpet and Silver Pearl leather trim (grey SX026)
    • Dashboard: Initially black vinyl and padded (for IVA), but I will be replacing it with Silver Grey leather and no padding (post-IVA)
    • Carpets: Black
    • Door Cards: Silver Grey
    • Seats: Silver Grey
    • Tunnel Top: Silver Grey leather panel (on top of the carpet)
    • Behind the seats: Black carpet and a silver-grey leather panel covering the top half
    • Head Restraints: Standard GD fixed to the roll-hoops and laser-cut logo on the back
  • Safety Belts: Black Willans 3-inch 4 x 4 harness type
  • Starter Button: Cobra Start (Pilgrim Motorsports)
  • Steering column stalks: Standard black plastic

Cooling:

  • Radiator: Very big and very Aluminium
  • Fan: 16-inch curved blade (Pull)
    • Note: I've also fitted a complementary pair of ECU-controlled 9-inch 'Push' fans in front of the radiator. See the Electrics - Modifications article for details.
  • Hoses & Connectors: Viper Performance
  • Manual heater valve controller (CBS)

Differential: BTR Hydratrack speed-sensitive limited-slip differential (3.07:1)

Engine: Built and Supplied by The Engine Factory (USA Company)

  • Ford V8 302 (5ltr, 350bhp) (Here is a video of my engine running at the factory.. Awesome..!)
    • Specifics:
      • Precision-machined 302 roller block painted with high-temp black enamel paint
      • Nodular cast crankshaft
      • Connecting rods with ARP retaining bolts
      • HYPERUECTECTIC 9.5 TO 1 compression pistons with DURALUBE coating
      • Perfect Circle Chrome MOLY piston rings
      • Three-piece steel roller-style timing chain
      • Hydraulic Steel Roller XTREME Energy camshaft
      • New MELLING oil pump and screen
      • Edelbrock RPM aluminium heads 60cc combustion chamber with bronze guides
      • 2.02 Stainless steel swirl polished intake valves
      • 1.60 stainless steel swirl-polished exhaust valves
      • Comp Cams Pro Magnum chrome MOLY steel roller rockers
      • Hard seats for unleaded or regular fuel
      • Heavy-duty 1.45 diameter valve springs, 7-degree locks
      • New heavy-duty chrome MOLY pushrods
      • Front sump: Canton (15-630S) Low Profile 8-quart oil pan with an extra bung for oil temp
      • Timing chain cover with scale
      • COBRA black wrinkled valve covers
      • 157-tooth standard flywheel (for 5-speed transmissions)
      • Edelbrock RPM dual plane intake manifold
      • MSD Atomic EFI fuel injection with Integral ECU, Wiring Harness, Sensors
      • ELECT. Billet ignition distributor w/45,000-volt coil
      • Yellow "Taylor" 8mm ignition leads
      • High-voltage electric fuel pump (MSD)
      • High-flow aluminium water pump
      • MSD ATOMIC oval air cleaner with PCV ventilated system
      • 3/8 EFI-rated fuel lines and Pre / Post gas filter
      • Chrome 100 Amp alternator - One wire hook-up
      • Complete MARCH underdrive polished pulley set (Pulleys kit)
      • Polished Chrome Alternator Bracket
      • SERPENTINE belt installed and tension adjusted
      • Steel bell-housing
      • 26 spline Clutch Kit
      • High Torque Starter
      • Hot run tested includes setting initial & full-timing advance
      • Video footage of the engine running in the test stand is provided
      • 'Blueprinted', assembled by ASE technicians
    • No oil cooler
    • Here is an example of what the Engine Factory uses in their engines.
  • MSD 6AL 6425 Ignition Box (added by me as an enhancement)
  • Gearbox: Tremec TKO500
    • Gear Ratios:
      • 3.27
      • 1.98
      • 1.34
      • 1.0
      • 0.68

Gearstick: Bowler 8-inch billet, 30° kickback style

Gearstick Gaiter: Hurst

Header / Expansion Tank: Round stainless steel type (GD supplied)

Steering Wheel: Moto-Lita 350 mm classic 6 bolt, 9 rivet, 3 spoke, dark stain

Tyres: 245 x 40 x 18" front, 275 x 40 x 18" rear. Michelin Pilot Sport/Super Sport (Tyre/rim size explained)

Wheels: 8.5 x 18” front, 10 x 18” rear. Halibrand GTD5 Classic build (all chrome) with a cover plate for 5-stud fitment and spinners
